Specification

AC Voltage: 208-230 / 240 V
Origin: CN(Origin)
Certification: CCC
Certification: ce
Certification: ROHS
Efficiency: IE 1
Phase: Three-phase
Protect Feature: Totally Enclosed
Type: Servo Motor
Model Number: 130J12225EC-2500+3HSS2208H
Frequency: 200K
Output Power: 35N.m
Current / Phase: 6.8A
Step Angle(degrees): 1.2
Holding Torque: 35N.m
Resistance phase(ohms): 0.92
inductance/ phase(mH): 13.8
Detent torque (gcm): 3000
lead wire numbers: 3
(kg) Length (mm): 277
Hybrid step servo drive: 3HSS2208H
drive current(A): 0-8A
drive Voltage(A): AC(110-240V)
drive size: 180*140*70
