Specification

Brand Name: Ben & Fellows
Model Number: 521880/521881
Type: Signal Processing
Input Channels: 8 balanced. Mic/line level
Connectors: 3.81 mm Phoenix Contact 12-pin
Input Impedance: 11.5KΩ
Maximum Input Level: 14dBu/Line -7dBu/Mic
Phantom Power: +48VDC 10mA selectable per input
Output Channels: 8 balanced line level
Output Impedance: 150Ω
Frequency Response: 20Hz-20kHz(+-0.5dB)/Line 20Hz-20kHz(+-1.5dB)/Mic
USB: Micro-B type free driver
RS232: Serial port communication
TCPIP: RJ-45 Optional
LED Status Indicators: Power Link +48V Input and Output Audio signal
Mains Voltage: AC100V---240V 50/60 Hz
Dimensions: 44mmx483mmx210mm
