Specification

Brand Name: Scodeno
Origin: CN(Origin)
Model Number: A80S
Splicing Time: 6 secs
Display: 5.0-inch TFT color LCD display reversible content convenient for two
Applicable fiber: SM (G.652&G.657) MM (G.651) DS (G.653) NZDS (G.655) and custom fibe
Heating Time: 15secs
Splicing Loss: 0.02dB(SM) 0.01dB(MM) 0.04dB(DS/NZDS)
Return loss: ≥60dB
Tension test: Standard 2N (optional)
Fiber Diameter: Cladding diameter 80-150um coating layer 250-1000um; 16mm
Cutting length: Coating≤250um: 8-16mm; Coating 250-1000um;16mm
Magnification: 400 times (x-axis or y-axis
Heat shrink sleeve: 60mm 40mm and a series of micro shrink sleeves
External interface: USB interface
Fusion mode: 17 group of operation modes
Heating mode: 9 group of operation modes
Continuous Loss Storage: Built-in memory holds 5000 latest continuous results
Power Saving Function: 15% lithium battery capacity can be saved in typical environment
Power supply: Built-in lithium battery 11.8V charging time ≤3.5 hours
Operating Environment: -10~50°C humidity < 95%RH (no condensation)
Dimensions: 158*130*156mm(L*W*H)
Weight: 1.17kg (without battery) 2.14kg (with battery)
