Specification

Origin: CN(Origin)
Type: Horizontal
Condition: New
Model Number: CD-210V
CNC or Not: Normal
Model: CD-210V
Motor: 750W brushless motor
Length X Width X Height: 850x310x320mm
Swing Over Bed: 210mm
Swing Over Cross Slide: 140mm
Distance Between Centers: 400mm
Width of Bed: 100mm
Spindle bore: 38mm
Chuck diameter: 3Jaw 125mm
Spindle taper: MT5
Number of Spindle Speeds: infinitely variable speeds
Range of Spindle Speeds: 50-2500RPM
Number of Inch Threads: 8
Range of Inch Threads: 10-44T.P.I
Range of Longitudinal Feed: 0.1-0.2mm
Tools rest labour: Horizontal four-station
Max Cutter Reat Stroke: 55mm
Max Stroke of big Pallet: 276mm
Max Stroke of Mid Pallet: 75mm
Tailstock Spindle Travel: 60mm
Tape in Tailstock Spindle: MT2
