Specification

Brand Name: RAK
State of Assembly: Ready-to-Go
Compatibility: Others
Bundle: RAK2245 Pi HAT with heat sink
Camera Equipped: No
Model Number: RAK7244
Computing: Raspberry Pi 4(Linux)
LoRa Module: RAK2245 Pi HAT with heat sink
Cellular Module: RAK2013 Cellular Module(Quectel EG95)
GPS Module: Ublox MAX-7Q GPS module
LoRa Frequency: 433MHz 470MHz 864MHz 865MHz 868MHz 915MHz 920MHz 923MHz
LoRaWAN Version: LoRaWAN V1.0.2
TX Power: 27dBm (Max) typical 25 dBm
RX Sensitivity: -139dBm(Min)@SF12 BW 125KHz
Power Supply: 5V / 2.5A
Working Environment: Indoor
Dimension (L x W x H): 92mm x 68.3mm x 53.5mm
Weight: Approximately 10.64 oz
Relative Humidity: 20% ~ 75% non condensing
Aluminium Casing: IP30
