Specification

Brand Name: TZT
Model Number: COFDM
working voltage: DC11V-DC13V
Encryption: support 128 encryption
Modulation mapping: QPSK (4QAM)16QAM64QQAM
Forward error correction: 1/22/33/45/67/8
Protect the interval: 1/321/161/81/4
Carrier number: 2K
Frequency bandwidth: 2/3/4/5/6/7/8M adjustable
transport stream: 2000kbs-20000kbs adjustable
transmission power: 0.5W/1W/2W optional
transmission frequency: could be customizedstep is 1Mhz
power flatness: less than 0.2db within10Mhz
Second harmonic: less than -45db
MER: 32db
input video: 1Vp-p75ohm
Video program format: MPEG-2
Video quality: 720x576 when above 4M
Format: NTSC and PAL could be setting
