Specification

Brand Name: TZT
Model Number: SAG6000L
keywords: Signal Generator
keywords 1: Spectrum Analyzer
keywords 2: Signal Source Tracking
Output Frequency Range: 25MHz-6GHz
Min. Stepper: 1K
Output Power(for reference): -2.35dBm@200M -2.63dBm@500M -2.69dBm@1G
Output Power 1: -2.89dBm@2G -2.66dBmBM@3G -5.36dBm@4G
Output Power 2: -7.65dBm@5G -10.42dBm@6G.
Frequency Accuary(After calibration): ±0.1k@1GHz
Max Liner Input for Spectrum Analyzer: -20dBm
Lossless Input for Spectrum Analyzer: +10dBm
Low Noise Input Signal Amplitude: -106DBM @ 0.5G
Power Supply: +5V/0.28AUSB2.0USB3.0
Interface: USB SMA
Size: 118 x 65 x 24mm (L*W*H)
Weight: 150g
