Specification

Brand Name: UNI-T
DIY Supplies: Electrical
Origin: CN(Origin)
Model Number: UT89X/UT89XD
AC Current: 60mA/600mA/20A
AC Voltage: 6V/60V/600V/1000V
Measuring Resistance Range: 100mF
Operating Mode: Manually
Measuring Inductance Range: N/A
Display Type: Digital Display
DC Current: 60miuA/60mA/600mA/20A
DC Voltage: 600mV/6V/60V/600V/1000V
Measuring Capacitance Range: 6nF/60nF/600nF/6uF/60uF/600uF/6mF/60mF/100mF
Dimensions: 189mm*89mm*53mm
Operating Temperature: 0 - 50 ℃
Frequency (Hz): 9.999Hz/9.999MHz
Duty cycle: 0.1%~99.9%
Temperature (Centigrade): -40centigrade~1000centigrade
Temperature Fahrenheit: -40 Fahrenheit~1832 Fahrenheit
Display count: 6000
Sampling rate: 3 times/s
True RMS: Yes
AC voltage frequency response: 45~1000Hz
AC current frequency response: 45~1000Hz
Live wire test: Yes
Diode/Continuity test: Yes
Transistor hFE: Yes
Dual range NCV test: Yes
Auto power off: Yes
Low battery indication: Yes
Data hold: Yes
Flashlight: Yes
Auto backlight: Yes
